Product is not available
TECHNICAL SPECIFICATIONS:
Model No : PEARL-2S
Max. Speed : Upto 80 bpm
Filling Capacity : 25 gm to 1000 gm
Min.Roll Size : 120 mm
Max.Roll Size : 520 mm
Supply Voltage : 415 VAC, 3-ph
Power : 4 kw
Air Consumption: 7 CFM
❖ SALIENT FEATURES
▪ Controlled by most advanced PLC from Mitsubishi - with touch screen operating panel.
▪ Integrated PID temperature controllers in PLC, precisely controls temperature within limits.
▪ Servo operated horizontal sealing for fast and better sealing.
▪ Servo operated bag pulling for fast and accurate bag pulling.
▪ Easy Forming assembly changeover.
▪ Recipe functions for easy job changeover.
▪ Air Shaft for easy Roll changeover.
▪ Motorized Web tracking System.
▪ Enough Safety devices used in control panel to protect.
▪ 3 speed VFD controlled motorized Roll unwinding controlled by 4 sensors.
▪ Sturdy and versatile construction of machine.
▪ Perforation attachment to offer chain of pouches.
